| Specifications |
| Membrane Housings: |
| High pressure, fiberglass reinforced plastic membrane housings |
| Frame: |
| Structural fiberglass and aluminum |
| Controller Power Requirements: |
| 120V/60Hz/1Ph |
| Motor Power Requirements: |
| 230-460V/60Hz/3Ph |
| Pumps: |
| Neutating disc design with positive displacement, brass pump head, buna diaphragm, and stainless steel valve and seat |
|
| |
| Operating Parameters |
| Operating Pressure: |
1,000 psi |
| Min. Supply Pressure: |
15 psi |
| Max. Temperature: |
113ºF (45ºC) |
| Nominal TDS: |
35,000 ppm |
| Max. Inlet Free Chlorine: |
< 0.1 ppm |
|
|
| Standard Features |
| • |
Energy efficient, high flow membranes |
| • |
5 micron sediment pre-filter |
| • |
Allen-Bradley programmable controller |
| • |
Liquid level float with auto shut-off |
| • |
Auto-flush system |
| • |
Pre- and post-filter, feed, concentrate, and product water pressure gauges |
| • |
Visual inline flow meters |
| • |
Low pressure feed water switch |
| • |
Victaulic style 304 stainless steel housing connections |
| • |
Low pressure alarm capable |
| • |
Motor starter with safety disconnect |
|
| |
| Optional Features |
| • |
2 m³d field portable system with gas or diesel powered generator |
| • |
Digital permeate TDS meter |
| • |
Automatic antiscalant dosing system |
| • |
Automatic or manual pH control dosing system |
| • |
Ethernet communication upgrade for the controller |
| • |
Digital permeate and concentrate flow meters with low level alarms |
| • |
Digital supply and concentrate pressure gauges with high level alarms |
| • |
Clean-in-place membrane maintenance station |
| • |
System shutdown during permeate flush |
| • |
Stainless steel wetted parts for liquid end of pump |
| • |
Step-down transformer from 3 phase to single phase |
| • |
Available in all international voltages |
|
| |
|
|
| |
| |
| RO Systems |
|
|
MODEL |
|
HTS-2-SEA
|
HTS-4-SEA
|
HTS-8-SEA
|
HTS-12-SEA
|
HTS-20-SEA
|
HTS-28-SEA
|
HTS-38-SEA
|
HTS-57-SEA
|
HTS-82-SEA
|
Actual Permeate
(m³d / gpd) |
0.38 /
100
|
1.13 /
300
|
1.9 /
500
|
3.8 /
1,000
|
11.4 /
3,000
|
29 /
7,600
|
38 /
10,000
|
57 /
15,000
|
76 /
20,000
|
Nominal Size
(m³d / gpd) |
1.9 /
500
|
1.9 /
500
|
1.9 /
500
|
4.5 /
1,200
|
13.6 /
3,600
|
36.3 /
9,600
|
54.5 /
14,400
|
82 /
21,600
|
114 /
30,000
|
| Recovery |
50-75%
|
50-75%
|
50-75%
|
50-75%
|
50-75%
|
50-75%
|
50-75%
|
50-75%
|
50-75%
|
Concentration
Rate (gpm) |
0.07
|
0.14
|
0.21
|
3.10
|
3.10
|
6.50
|
6.90
|
9.60
|
12.80
|
Recycle Rate
(gpm) |
0.0
|
0.0
|
0.0
|
0.0
|
0.0
|
0.0
|
0.0
|
0.0
|
9.7
|
Supply Rate
(gpm) |
1.7
|
1.7
|
1.7
|
3.8
|
5.1
|
11.7
|
13.9
|
20.0
|
26.7
|
RO Pump Design
Flow (gpm) |
1.7
|
1.7
|
1.7
|
3.8
|
5.1
|
11.7
|
13.9
|
20.0
|
36.4
|
RO Pump Design
Pressure (psi) |
450.0
|
679.0
|
807.0
|
950.0
|
1,050.0
|
1,050.0
|
1,050.0
|
1,050.0
|
1,050.0
|
RO Motor H.P.
(60 Hz) |
2.0
|
2.0
|
5.0
|
5.0
|
5.0
|
10.0
|
15.0
|
20.0
|
25.0
|
RO Motor
KWH @ Flow |
0.58
|
0.88
|
1.04
|
2.75
|
4.08
|
9.35
|
11.11
|
20.00
|
24.80
|
CIP Pump Design
Flow (gpm) |
10
|
10
|
10
|
10
|
20
|
20
|
20
|
30
|
30
|
CIP Pump Design
Pressure (psi) |
60
|
60
|
60
|
60
|
60
|
60
|
60
|
60
|
60
|
CIP Motor H.P.
(60 Hz) |
1
|
1
|
1
|
1
|
2
|
2
|
2
|
3
|
3
|
CIP Motor
KWH @ Flow |
0.91
|
0.91
|
0.91
|
0.91
|
1.83
|
1.83
|
1.83
|
2.74
|
2.74
|
Chemical
Pretreatment |
Optional
|
Optional
|
Optional
|
Optional
|
Required
|
Required
|
Required
|
Required
|
Required
|
| Membrane Elements |
|
|
HTS-2-SEA
|
HTS-4-SEA
|
HTS-8-SEA
|
HTS-12-SEA
|
HTS-20-SEA
|
HTS-28-SEA
|
HTS-38-SEA
|
HTS-57-SEA
|
HTS-82-SEA
|
Diameter
(in / cm) |
4 /
10.16
|
4 /
10.16
|
4 /
10.16
|
4 /
10.16
|
4 /
10.16
|
4 /
10.16
|
4 /
10.16
|
8 /
20.32
|
8 /
20.32
|
| Number |
1
|
1
|
1
|
2
|
3
|
8
|
12
|
18
|
6
|
Pressure
Vessel Array
|
1-0
|
1-0
|
1-0
|
1-1
|
3-0
|
2*4
|
2*6
|
3*6
|
6-0
|
| Connections NPS & DN |
|
|
HTS-2-SEA
|
HTS-4-SEA
|
HTS-8-SEA
|
HTS-12-SEA
|
HTS-20-SEA
|
HTS-28-SEA
|
HTS-38-SEA
|
HTS-57-SEA
|
HTS-82-SEA
|
Inlet
(in / mm) |
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.75 /
20
|
.75 /
20
|
1 /
25
|
1 /
25
|
1 /
25
|
Permeate
(in / mm) |
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.75 /
20
|
1 /
25
|
1 /
25
|
Concentration
(in / mm) |
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.5 /
15
|
.75 /
20
|
.75 /
20
|
| Estimated Footprint |
|
|
HTS-2-SEA
|
HTS-4-SEA
|
HTS-8-SEA
|
HTS-12-SEA
|
HTS-20-SEA
|
HTS-28-SEA
|
HTS-38-SEA
|
HTS-57-SEA
|
HTS-82-SEA
|
Height
(in / cm) |
30 /
76
|
30 /
76
|
30 /
76
|
30 /
76
|
36 /
91
|
36 /
91
|
60 /
152
|
60 /
152
|
60 /
152
|
Width
(in / cm) |
48 /
122
|
48 /
122
|
48 /
122
|
48 /
122
|
48 /
122
|
166 /
422
|
246 /
625
|
246 /
625
|
246 /
625
|
Depth
(in / cm) |
24 /
61
|
24 /
61
|
24 /
61
|
24 /
61
|
24 /
61
|
24 /
61
|
30 /
76
|
30 /
76
|
30 /
76
|
| Estimated Weight |
|
|
HTS-2-SEA
|
HTS-4-SEA
|
HTS-8-SEA
|
HTS-12-SEA
|
HTS-20-SEA
|
HTS-28-SEA
|
HTS-38-SEA
|
HTS-57-SEA
|
HTS-82-SEA
|
Shipping
(lbs / Kgr) |
245 /
111.2
|
245 /
111.2
|
245 /
111.2
|
270 /
122.5
|
305 /
138.3
|
405 /
184
|
445 /
202
|
525 /
239
|
730 /
330
|
Installed
(lbs / Kgr) |
204 /
92.5
|
204 /
92.5
|
239 /
108.4
|
239 /
108.4
|
297 /
134.7
|
321 /
145.6
|
455 /
206.4
|
526 /
238.6
|
601 /
272.6
|
|
| |
|
