| Reverse Osmosis |
 |
Commercial RO Systems |
 |
 STANDARD FEATURES
|
 |
 |
 |
|
|
| OPERATING SPECIFICATIONS |
|
| Max. Feed Water Temperature: | 85°F (29°C) |
| Max. Feed Water TDS: | 2000 ppm |
| Feed Water Pressure: | 25-85 psi |
| Max. Operating Pressure: | 165 psi |
| pH Range: | 4.0-11.0 |
| Turbidity: | Less than 1 NTU |
| Iron: | Maximum tolerance 0.5 ppm (Dissolved only) |
| Hardness: | Over 10 gpg should be softened |
| Hydrogen Sulfide: | Must be removed |
| Salt Rejection: | 98% nominal |
| Test Conditions: | Feed Water: 1,500 ± 100 ppm NaCl Operating Temperature: 77°F (25°C) pH Range: 7.5 - 8.5 Recovery: 15% ± 5% |
| 400 to 1900 GPD Systems |
| Part Number | Description | GPD | LPD | Electricity Required |
| RG-939004006 | BLS-400 |
400 |
1,514 |
115V/60Hz/1Ph |
| RG-939004005 |
BLS-400 |
400 |
1,514 |
230V/50Hz/1Ph |
| RG-939008006 | BLS-800 |
800 |
3,028 |
115V/60Hz/1Ph |
| RG-939008005 | BLS-800 |
800 |
3,028 |
230V/50Hz/1Ph |
| RG-939009506 | BLS-950 |
950 |
3,596 |
115V/60Hz/1Ph |
| RG-939009505 | BLS-950 |
950 |
3,596 |
230V/50Hz/1Ph |
| RG-939019006 | BLS-1900 |
1900 |
7,192 |
115V/60Hz/1Ph |
| RG-939019005 | BLS-1900 |
1900 |
7,192 |
230V/50Hz/1Ph |
| Includes: Price includes: Sediment pre-filter (5 micron), high flow membranes, 2.5" PVC membrane housings, reject water recirculating loop, pre-treatment lockout connection, automatic feed water shut-off, manual flush valve, epoxy coated steel frame, low pressure protection switch, permeate check valve, tank level control connection, and is completely assembled and pre-tested. |
| 3000 to 18000 GPD Systems |
| Part Number | Description | GPD | LPD | Electricity Required |
| RG-939030006 | BLS-3000 | 3,000 | 11,355 | 230V/60Hz 1 Phase |
| RG-939030005 | BLS-3000 | 3,000 | 11,355 | 220V/50Hz 1 Phase |
| RG-939060006 | BLS-6000 | 6,000 | 22,710 | 230V/60Hz 1 Phase |
| RG-939060005 | BLS-6000 | 6,000 | 22,710 | 380V/50Hz 3 Phase |
| RG-939090006 | BLS-9000 | 9,000 | 34,065 | 230V/60Hz 1 Phase |
| RG-939090005 | BLS-9000 | 9,000 | 34,065 | 380V/50Hz 3 Phase |
| RG-939120006 | BLS-12000 | 12,000 | 45,420 | 460V/60Hz 3 Phase |
| RG-939120005 | BLS-12000 | 12,000 | 45,420 | 380V/50Hz 3 Phase |
| RG-939150006 | BLS-15000 | 15,000 | 56,775 | 460V/60Hz 3 Phase |
| RG-939150005 | BLS-15000 | 15,000 | 56,775 | 380V/50Hz 3 Phase |
| RG-939180006 | BLS-18000 | 18,000 | 68,130 | 460V/60Hz 3 Phase |
| RG-939180005 | BLS-18000 | 18,000 | 68,130 | 380V/50Hz 3 Phase |
| Includes: Price includes: Sediment pre-filter (5 micron), high flow membranes, 4” stainless steel membrane housings, reject water recirculating loop, pre-treatment lockout connection, automatic feed water shut-off, manual flush valve, epoxy coated steel frame, low pressure protection switch, permeate check valve, tank level control connection, and is completely assembled and pre-tested. |
| Available Options & Accessories |
| Part Number | Description | Model |
| RG-93901 | Carbon Pre-Filter, 10” Housing w/ 10 Micron Carbon Block | BLS-400/800 |
| RG-93902 | Carbon Pre-Filter, 20” Housing w/ 10 Micron Carbon Block | BLS-950/1900 |
| RG-93903 | Gauges, Pre & Post Filter, Liquid Stem Mount | All BLS Systems |
| RG-93904 | Gauges, Pre, Post & Product, Liquid Panel Mount | BLS-950/1900 |
| RG-93904-30 | Gauges, Pre, Post & Product, Liquid Panel Mount | BLS-3000 thru 18000 |
| RG-93905 | Product Water Pressure Switch (For Pressurized Storage
Tank) |
All BLS Systems |
| RG-0050201 | Tank Level Float Control for Potable Water (For Atmospheric
Tank) |
All BLS Systems |
| RG-0050200 | Tank Level Float Control for Non-Potable Water (For Atmospheric Tank) | All BLS Systems |
| RG-93906 | Product Water Pressure Relief Valve |
All BLS Systems |
| RG-93907 | TDS In-line Monitor with Red & Green Light |
BLS-400 thru 1900 |
| RG-93908 | TDS Digital Meter |
All BLS Systems |
| RG-93909 | Product & Reject Flow Meters |
BLS-400 thru 1900 |
| RG-93909-30 | Product & Reject Flow Meters |
BLS-3000/6000 |
| RG-93909-90 | Product & Reject Flow Meters |
BLS-9000 |
| RG-93909-120 | Product & Reject Flow Meters |
BLS-12000 thru 18000 |
| RG-93910-30 | Automatic Flush System |
BLS-3000 thru 9000 |
| RG-93910-120 | Automatic Flush System |
BLS-12000 thru 18000 |
| RG-93911 | Time Delay Air Purge | All BLS Systems |
| RG-93912 | Stainless Steel Pump Upgrade for 60Hz | BLS-400 thru 1900 |
| RG-93912-30 | Stainless Steel Pump Upgrade for 60Hz | BLS-3000 thru 9000 |
| RG-93912-120 | Stainless Steel Pump Upgrade for 60Hz | BLS-12000 thru 18000 |
| RG-93913 | Stainless Steel Pump Upgrade for 50Hz | BLS-400 thru 1900 |
| RG-93913-30 | Stainless Steel Pump Upgrade for 50Hz | BLS-12000 thru 18000 |
| RG-93913-120 | Stainless Steel Pump Upgrade for 50Hz | BLS-12000 thru 18000 |
| RG-93916-4 | Stainless Steel Pressure Vessels Upgrade, (1) 2.5”
x 21” |
BLS-400 |
| RG-93916-8 | Stainless Steel Pressure Vessels Upgrade, (2) 2.5”
x 21” |
BLS-800 |
| RG-93916-9 | Stainless Steel Pressure Vessels Upgrade, (1) 2.5”
x 40” |
BLS-950 |
| RG-93916-19 | Stainless Steel Pressure Vessels Upgrade, (2) 2.5”
x 40” |
BLS-1900 |
