100% Polypropylene (PP) Absolute Cartridges

Absolute Cartridges

100% PP Membrane Cartridges

HOUSINGS & CARTRIDGES INDEX | CARTRIDGES INDEX | DOWNLOAD PDF

For a wide variety of general process applications — from fluids clarification to general prefiltration — SWT has developed the 100% Polypropylene Absolute Cartridge product line.

SWT’s 100% Polypropylene (PP) Membrane Cartridges are fabricated using high dirt-loading, random fiber polypropylene depth media that provides consistent particle retention. Longer filtration life reduces cartridge purchases, downtime due to change-outs, and disposal costs. SWT’s 100% Polypropylene Membrane Cartridges lead in overall reduction of filtration costs when compared to spun-bonded, string wound, and normally-rated pleated prefilter cartridges.

Fabrication using strictly virgin polypropylene components combined with thermal bonding results in excellent chemical compatibility, thermal stability, and low cartridge extractables. SWT’s 100% Polypropylene Membrane Cartridges are manufactured in a controlled environment and are bulk packaged to reduce material disposal costs.

	ADVANTAGES:
	•	All materials meet FDA/USP requirements
	•	High flow rates, long on-stream life
	•	Broad chemical compatibility
	•	USP Class VI-121ºC certified
	•	Low differential pressures
	•	Thermally bonded
	•	Low extractables

Applications:

Solvent filtration; liquid clarification; recirculating liquids; general water filtration; reagent grade chemicals; beverage/wine clarification; RO/DI pre-filtration; waste water

Specifications

Available Nominal Pore Size Ratings:
0.2, 0.5, 1.0, 3.0, 5.0, 10.0, 30.0 micron

Materials of Construction:

— Depth Media: Polypropylene
— Support Layers: Polypropylene
— Housing: Polypropylene

Max. Operating Temperature:
160ºF (71ºC)

Max. Differential Pressure:

— Forward: 80 psid (5.5 bar) @ 75ºF (24ºC)
— Reverse: 40 psid (2.8 bar) @ 75ºF (24ºC)

Biosafety:
All components meet USP-XXIII Class VI-121ºC criteria

Sealing Methods:
All components are thermally bonded to assure integrity and to reduce extractables

Packaging:
Bulk packaged in case quantities to reduce material disposal

— 10 inch: 28 per carton
— 20 inch: 12 per carton
— 30 inch: 12 per carton
— 40 inch: 9 per carton

Ordering Information

0.1 Micron 100% Polypropylene Absolute Filter Cartridges
0.2 Micron 100% Polypropylene Absolute Filter Cartridges
0.45 Micron 100% Polypropylene Absolute Filter Cartridges
0.5 to 70 Micron 100% Polypropylene Absolute Filter Cartridges
