| Commercial Water Softeners |
|
Computer Controlled Water Softeners |
|
Safe
Water Technologies' Corrosion Proof Water Softeners are
built utilizing SWT's ProSoft™ Resin
as the primary layer. These cationic ion exchange systems are designed
to remove calcium and magnesium (hardness), and a host of other
cations from the water. SWT takes care of the little extras such
as: machined PVC distribution systems, oversized brine tanks, safety
float for 16 inch or larger systems, and an anthracite under-bedding
for less channeling.
|
|||||
| Part Number |
Tank Size Inches |
CaCO3 Capacity @ 6 lbs./Ft³ Grains |
CaCO3 Capacity @ 10 lbs./Ft³ Grains |
CaCO3 Capacity @ 15 lbs./Ft³ Grains |
Service Standard Flow Rate GPM (LPM) |
Service Peak Flow Rate GPM (LPM) |
Backwash 50% Exp. @ 60ºF GPM (LPM) |
Standard Connection Size |
Approx. Weight lbs. (kg) |
| WSC961-50 | 7 x 44 |
11,900 |
15,100 |
17,200 |
3 (11.4) |
6 (22.7) |
1.2 (4.6) |
3/4" FPT |
80 (36.5) |
| WSC961-75 | 8 x 44 |
17,850 |
22,650 |
25,800 |
4 (15.2) |
8 (30.3) |
1.6 (6.1) |
3/4" FPT |
85 (38.8) |
| WSC961-10 | 9 x 48 |
23,800 |
30,200 |
34,400 |
5 (19.0) |
10 (37.9) |
2.0 (7.6) |
3/4" FPT |
115 (52.5) |
| WSC961-15 | 10 x 54 |
35,700 |
45,300 |
51,600 |
7.5 (28.3) |
15 (56.9) |
2.5 (9.5) |
3/4" FPT |
135 (61.6) |
| WSC961-20 | 12
x 52 |
47,600 |
60,400 |
68,800 |
10
(37.9) |
15
(56.9) |
3.5
(13.6) |
3/4"
FPT |
175
(79.9) |
| WSC961P-20 | 12 X 52 |
47,600 |
60,400 |
68,800 |
10 (37.9) |
20 (75.7) |
3.5 (13.6) |
1" Cu Tb |
175 (79.9) |
| WSC961P-25 | 13 x 54 |
59,500 |
75,500 |
86,000 |
12 (45.5) |
24 (90.9) |
4.1 (15.5) |
1" Cu Tb |
185 (84.1) |
| WSC961P-30 | 14 x 65 |
71,400 |
90,600 |
103,200 |
15 (56.9) |
25 (94.6) |
4.5 (17.0) |
1" Cu Tb |
275 (125) |
| WSC961P-40 | 16 x 65 |
95,200 |
120,800 |
137,600 |
20 (75.7) |
25 (94.6) |
5.0 (18.9) |
1" Cu Tb |
300 (136) |
| WSC961P-50 | 18 x 65 |
119,000 |
151,000 |
172,000 |
25 (94.6) |
25 (94.6) |
7.0 (26.5) |
1" Cu Tb |
360 (164) |
| WSC961P-60 |
21 x 54 |
142,000 |
181,200 |
206,400 |
25 (94.6) |
25 (24.6) |
9.0 (37.1) |
1" Cu Tb |
465 (211) |
| WSC961P-70 |
21
x 69 |
166,600 |
211,400 |
240,800 |
25
(94.6) |
25
(24.6) |
9.0
(37.1) |
1"
Cu Tb |
550
(250) |
| WSC962-40 | 16 x 65 |
95,200 |
120,800 |
137,600 |
20 (75.8) |
33 (125) |
5.0 (18.9) |
1.5" MPT |
330 (151) |
| WSC962-50 | 18 x 65 |
119,000 |
151,000 |
172,000 |
25 (94.8) |
50 (190) |
7.0 (26.5) |
1.5" MPT |
400 (183) |
| WSC962-60 | 21 x 54 |
142,800 |
181,200 |
206,400 |
30 (114) |
60 (227) |
9.0 (37.1) |
1.5" MPT |
475 (217) |
| WSC962-70 | 21 x 69 |
166,600 |
211,400 |
240,800 |
35 (133) |
70 (265) |
9.0 (37.1) |
1.5" MPT |
560 (256) |
| WSC962-95 | 24 x 72 |
226,100 |
286,900 |
326,800 |
45 (171) |
90 (341) |
12.0 (45.4) |
1.5" MPT |
740 (338) |
| WSC962-140 | 30 x 72 |
333,200 |
422,800 |
481,600 |
70 (265) |
100 (379) |
19.0 (71.9) |
1.5" MPT |
1135 (518) |
| WSC962-180 | 36 x 72 |
428,400 |
543,600 |
619,200 |
90 (341) |
100 (379) |
27.0(102.2) |
1.5" MPT |
1500 (684) |
| WSC962-270 | 42 x 72 |
642,600 |
815,400 |
928,800 |
90 (341) |
100 (379) |
45.0(170.3) |
2" Socket |
2500(1133) |
| International voltages available. Operating capacity based on influent of 400 ppm as CaCO3 with ratio of 2 parts calcium to 1 part magnesium. 1.5 inch systems have a 2 inch Inlet/Outlet option available. 1.5 inch and 2 inch systems have a no-unfiltered-water bypass option available. Operating pressure: 25 to 150 psi (1.7 to 10.3 bar) Operating temperature: 36 to 120ºF (2 to 48.9ºC) All pressure vessels are wound fiberglass, reinforced polyethylene, and are NSF® listed. |
 |
|
Notes:
All softeners for municipal water systems come with an upper screen as standard equipment. Other installation fittings are available on request. Resin ratings are as follows:
In basic terms, crosslinkage refers to the resin beads physical strength or ability to withstand chemical attack from chlorine, resin bed cleaners, and caustics used in DI applications. To a lesser extent, a higher crosslink also gives resin slightly higher softening capacity and a better affinity for iron. |
XX | Notes:
Almost all standard softening resins in the market range from 6.5% to 8% crosslink. If the water softener is on a chlorinated system, or sitting outside where high temperatures can weaken resin, then lower crosslink resins have a tendency to breakdown, lose capacity, and turn mushy over time . Generally speaking, the higher the crosslink, the better (and more expensive) the resin. 10% crosslink resins are generally too expensive for residential use and are found in mostly DI and industrial applications. Fine mesh resins, which are smaller than standard size resin beads, slightly increase the softeners capacity, speed up softening reaction time, and increases the ability to filter fine particles from the water supply. These are good for dual bed systems because they help retain the smaller, lighter anion resin beads on the top layer. They are also popular in cabinet style water softeners with shallower resin beds. |
||||||||||||||||||
|
